REPLACEMENT LTL123YL01-007 Microsoft Surface Pro 4 1724 Touch Screen Assembly
LTL123YL01-007 LCD Screen Assembly 12.3" for Microsoft Surface pro 4 2736x1824
Overview
BrandSamsungModel P/NLTL123YL01-001
Diagonal Size12.3"Panel TypeOxide TFT-LCD, LCM
Resolution2736(RGB)×1824 267PPI Pixel FormatRGB Vertical Stripe
Active Area259.783(W)×173.189(H) mmBezel Opening-
Outline Dim.265.38(H)×183.49(V) ×4.42(D) mmTreatmentGlare (Haze 0%), Hard coating
Luminance450 cd/m² (Typ.)Contrast Ratio1400:1 (Typ.) (TM)
View DirectionSymmetryResponse Time27 (Max.)(Tr+Td), 46 (Typ.)(G to G)
Viewing Angle85/85/85/85 (Typ.)(CR≥10) Left / Right / Up / DownOperating ModePLS, Normally Black, Transmissive
Support Color16.7M 100% sRGBLight SourceWLED [6S8P] , 12K hours , W/O Driver
Weight148/157g (Typ./Max.)Designed ForPad & Tablet
Frame Rate60HzTouch PanelWithout
Interface TypeeDP (4 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 50 pins Connector
Power Supply3.3V (Typ.)
EnvironmentOperating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
Highlights
P/N: LTL123YL01
