Samsung PM981 256GB M.2 2280 NVMe PCIe Gen3x4 Internal SSD

The Samsung PM981 256GB M.2 2280 NVMe PCIe SSD (Model / Part Number: MZVLB256HAHQ-000H1) is a high-performance Client OEM solid-state drive built by Samsung. Designed as a ultra-fast primary storage solution for desktop systems and modern laptops, it provides rapid OS boot times, near-instant software loading, and high-speed data access—delivering speeds 5 to 6 times faster than standard SATA drives.

Leveraging a PCIe Gen3 x4 NVMe protocol alongside Samsung's proprietary Phoenix controller (S4LR020) and 64-layer 3D V-NAND flash memory, the PM981 achieves sequential read speeds up to 3,000 MB/s and sequential write speeds up to 1,300 MB/s. It features an intelligent pseudo-SLC cache system up to 25 GB for rapid sustained burst transfers, as well as random read/write speeds up to 130,000 / 310,000 IOPS for smooth multitasking.

Available from DataDive, your trusted IT hardware and component provider in Qatar, this original Samsung OEM solid-state drive incorporates hardware-based AES 256-bit encryption (Self-Encrypting Drive) to keep sensitive data protected without degrading performance, making it an ideal, secure choice for system builders and OEM laptop upgrades.

Key Features:

• High-speed 256 GB NVMe M.2 SSD engineered with Samsung's 64-layer 3D V-NAND technology

• PCIe Gen3 x4 interface supporting NVMe protocol for high throughput and reduced latency

• Sequential read speeds up to 3,000 MB/s and write speeds up to 1,300 MB/s

• Powered by Samsung’s proprietary Phoenix controller (S4LR020) for optimal reliability

• Intelligent pseudo-SLC cache system (up to 25 GB) to accelerate heavy file transfer workloads

• Self-Encrypting Drive (SED) with AES 256-bit hardware encryption for data protection

• Standard M.2 2280 form factor (22mm x 80mm) with M-Key plug for broad laptop and PC motherboard support

Technical Specifications:

• Brand: Samsung

• Series: PM981 Series (Client OEM)

• Model / Part Number: MZVLB256HAHQ-000H1

• Product Type: Internal Solid State Drive (SSD)

• Capacity: 256 GB (Approx. 238.5 GB usable)

• Form Factor: M.2 2280 (80mm Length, M-Key)

• Interface: PCIe Gen3 x4, NVMe 1.2

• Controller: Samsung Phoenix / S4LR020 In-House Controller

• NAND Flash Type: Samsung 64-Layer 3D V-NAND (TLC/MLC)

• Sequential Read Speed: Up to 3,000 MB/s

• Sequential Write Speed: Up to 1,300 MB/s

• Random Read (4KB): Up to 130,000 IOPS

• Random Write (4KB): Up to 310,000 IOPS

• Cache System: Intelligent Pseudo-SLC Cache (Up to 25 GB)

• Security Encryption: Self-Encrypting Drive (SED), AES 256-bit Hardware Encryption

• Application / Compatibility: Desktop PCs, OEM Laptops, Workstations, and Standard M.2 2280 PCIe NVMe Slots
