The HP USB-C Dock G5 Universal Docking Station (5TW10AA / N59407-001) is engineered to deliver seamless single-cable connectivity, high-speed data expansion, and multi-display desktop output for enterprise laptops and workstations. Featuring a compact 5x5 inch space-saving footprint, it allows users to connect their host notebook to external monitors, peripheral networks, and power infrastructure through a single tethered USB-C cable.
Equipped with two DisplayPort 1.4 outputs and one HDMI 2.0 port, the USB-C Dock G5 supports up to three external 4K displays depending on host system GPU capabilities. It delivers up to 100W of power pass-through to host laptops via USB Type-C Power Delivery while providing four USB 3.2 Gen 1 Type-A charging ports, an additional front USB-C data/power port, a 3.5mm combo audio jack, and an integrated Gigabit Ethernet port for fast wired network connectivity.
Available from DataDive, your trusted Technology Hardware Supplier in Qatar, this genuine HP USB-C G5 docking station is available in our Networking components collection, ideal for enterprise hot-desking setups, remote workstation configurations, IT fleet management, and multi-monitor office productivity environments across HP EliteBook, ProBook, ZBook, and non-HP USB-C platforms.
Key Features:
-
Universal single-cable USB-C connectivity provides power, video output, and data transmission simultaneously
-
Multi-display flexibility via 2 x DisplayPort 1.4 and 1 x HDMI 2.0 ports supporting up to triple 4K display configurations
-
USB Type-C Power Delivery supplies up to 100W of charging power directly to connected host laptops
-
Advanced enterprise network manageability features including PXE Boot, Wake-on-LAN (WoL), and MAC Address Pass-Through
-
Four USB 3.2 Gen 1 Type-A ports and one front USB-C port for rapid peripheral charging and high-speed data transfer
Technical Specifications:
-
Brand: HP (Hewlett-Packard)
-
Product Model: HP USB-C Dock G5
-
Part Number / SPS: N59407-001 / 5TW10AA (Alternative P/Ns: 26D32AA, 5TW10UT, 5TW10ET)
-
Host Connection: Tethered USB Type-C 3.2 Gen 1 Cable (1.0m length)
-
Power Delivery (PD to Host): Up to 100W (75W/65W on non-HP systems)
-
Video Interfaces: 2 x DisplayPort 1.4, 1 x HDMI 2.0
-
USB Ports: 4 x USB 3.2 Gen 1 Type-A (charging ports), 1 x Front USB 3.2 Gen 1 Type-C (data & 15W power out)
-
Network Interface: 1 x RJ45 Gigabit Ethernet (10/100/1000 Mbps)
-
Audio Port: 1 x 3.5mm Headphone/Microphone Combo Audio Jack
-
Network Manageability: PXE Boot, LAN/WLAN Switching, Wake-on-LAN (WoL), MAC Address Pass-Through
-
Security: Integrated Standard Kensington Lock Slot
-
Dimensions (L x W x H): 122 x 122 x 45 mm (4.80 x 4.80 x 1.77 in)
-
Compatibility: HP Commercial Notebooks (EliteBook, ProBook, ZBook), Apple MacBooks, Chromebooks, and Windows USB-C / Thunderbolt-enabled laptops
