for X3650 M2/M3/M4 146G 15K SAS Hard Disk 42D0677 42D0678 42D0681
Model No 42D0681 SKU HDD-IBM-SAS-42D0681

for X3650 M2/M3/M4 146G 15K SAS Hard Disk 42D0677 42D0678 42D0681

42D0677/42D0678/42D0679/42D0681/26K0678-9FU066-039-IBM 146GB 15K 6Gbps 2.5" SAS

Overview

The IBM 146GB 15K rpm SAS-2 6GBps 2.5-inch Slim HDDs provide 2.5-inch form factor that can be used as Hot-Swap drives. The addition of a 146 GB 15K rpm offering to the System x and BladeCenter blade family of 2.5-inch SAS HDDs makes it one of the highest-performing SFF options. These drives are positioned at the top of the SAS SFF HDD line based on increased performance and capacity.

Highlights

IBM 146GB serial Attached SCSI 2 (SAS-2) 6Gb/s 15K 2.5-inch Slim Hot-Swap Hard Drive

Specifications

Category IBM HardDrive Sub-Category 15K Generation SAS Part Number 42D0681 Products ID 461309 Capacity 146GB Interface SAS-2 Enclosure Internal HDD Form Factor 2.5 inches Spindle Speed 15000RPM External Data Transfer Rate 6G = 6Gb/sec (750 MB/s) Seek Time 2.9ms Buffer Size 16MB Average Latency 2ms Interface (Detailed) Serial Attached SCSI 2 (SAS-2) Hot Swap Yes
