Dell NVIDIA Quadro NVS 300 512MB DDR3 Low-Profile GPU (4M1WV)

Dell NVIDIA Quadro NVS 300 512MB DDR3 Low-Profile GPU (4M1WV)

Model No: 04M1WV SKU: GC-DEL-04M1WV
Dell 4M1WV X3MPP Nvidia Quadro NVS 300 512MB DDR3 DMS-59 PCIe x16

DELL
View full details

Product Description

The Dell NVIDIA Quadro NVS 300 512MB DDR3 Graphics Card (Dell Part Numbers: 04M1WV / 4M1WV / X3MPP) is an energy-efficient, multi-display business graphics solution engineered for high-density corporate desktop fleets, financial workstations, and office setups. Powered by NVIDIA's enterprise NVS architecture paired with 512MB of dedicated DDR3 video memory, this adapter provides dependable 2D rendering and fluid multi-window multitasking across dual-monitor configurations.

Designed for broad system deployment across small form factor (SFF) and standard tower chassis, the Quadro NVS 300 features a single DMS-59 output connector. When paired with a DMS-59 breakout Y-splitter cable, it drives two independent digital or analog monitors simultaneously (via dual DVI or dual VGA) at sharp display resolutions. Operating via a PCI Express x16 slot interface, the GPU consumes under 18W of maximum power, eliminating the need for external power cables while utilizing an active single-slot cooling fan for low-noise thermal efficiency.

Procured directly through DataDive, your trusted IT Hardware Supplier in Qatar, this original Dell NVIDIA Quadro NVS 300 is featured in our GPU / Accelerator collections, offering an affordable, highly reliable solution for dual-screen business workstations, office PC upgrades, and commercial desktop maintenance.

Key Features:

  • Low-profile, single-slot form factor designed for small form factor (SFF) and standard desktop PCs

  • 512 MB DDR3 dedicated frame buffer memory for efficient multi-window enterprise applications

  • Single DMS-59 connector supporting dual independent displays via breakout Y-splitter cables (dual DVI / VGA)

  • Ultra-low power consumption (~17.5W max TDP) running entirely off PCI Express slot power

  • Active single-slot cooling system featuring a low-noise fan and integrated heatsink for long-term stability

  • Reliable multi-monitor desktop management optimized for commercial enterprise operating systems

Technical Specifications:

  • Brand: Dell / NVIDIA

  • GPU Series: NVIDIA NVS Series

  • GPU Model: NVIDIA Quadro NVS 300

  • Dell Part Numbers (MPN): 04M1WV, 4M1WV, X3MPP

  • VRAM Capacity: 512 MB

  • VRAM Type: DDR3 SDRAM

  • Memory Interface Width: 64-bit

  • Host Interface: PCI Express x16 (PCIe 2.0 / 3.0 slot compatible)

  • Video Output Connector: 1 x DMS-59 Flex Connector

  • Max Simultaneous Displays: 2 Independent Monitors (via DMS-59 Y-splitter)

  • Max Digital Resolution: Up to 1920 x 1200 @ 60Hz (DVI)

  • Max Analog Resolution: Up to 2048 x 1536 @ 85Hz (VGA)

  • Power Consumption (TDP): ~17.5 Watts (No auxiliary power cable required)

  • Cooling Solution: Active Single-Slot Fan with Heatsink

  • Form Factor: Low Profile / SFF Compatible

  • Application / Compatibility: Dell OptiPlex Desktop PCs, Precision Workstations, Commercial Office Terminals, and Dual-Display Workspaces
